Substation topside installed at Seagreen wind farm
The 4,800 tonne offshore substation topside has been installed at the Seagreen offshore wind farm.
Scotland’s largest fixed bottom offshore wind farm and the world’s deepest, Seagreen, currently under construction off the Angus coast, has passed another significant milestone with the successful installation of the 4,800 tonnes offshore platform topside.
The topside forms the backbone of the offshore wind farm. At 40 metres long, 45 metres wide and 15 metres high, the heavyweight superstructure’s role is to collect and manage 1,075MW of power generated by the 114 Vestas wind turbines before transferring it ashore via around 60km of offshore subsea cabling.
Once onshore, the electricity continues to the new Tealing substation near Dundee via a further 19km of cabling for onward distribution to homes and businesses via the national electricity network.
The topside was lifted from a heavy transport vessel and onto the previously installed 6-legged jacket foundation. The completed structure sits in water depths of around 55m and will be one of the largest AC platforms in UK waters.
Specialist cable installation and support vessels will continue to install the onsite inter-array network of cables to the turbines and to the offshore platform. Another vessel is currently installing the export cable from the landfall point at Carnoustie.
“Once again, the many years of careful design and planning have come to fruition with the arrival and successful installation of one of the UK’s largest offshore AC platforms, serving what will become Scotland’s largest offshore wind farm.”, John Hill, Director of the Seagreen Wind Farm Project.
Source and image: SSE
